Fruit Grain Beverage Drinking Water Filling Line Production Machine UV Sterilized

MOQ:	1
Price:	USD 3000~2000000
Packaging Details:	wooden box or pallet
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Production Line Length:

Customized According To Customer's Requirements

Filling Material:

Drinking Water,Mineral Water

Machine Efficiency:

≥95%

After-Sales Service:

Engineers Available To Service Machinery Overseas

Automatic Grade:

Automatic

Bottle Sterilization Type:

UV Sterilization

Control System:

PLC Control

Applicable Bottle Type:

PET Bottle

Supply Ability:

30 lines per year

Highlight:

Grain Beverage Water Filling Line

UV sterilized Water Filling Line

Beverage water production machine

Product Description

Product Description:

The small fruit grain machine is a special equipment for one-time filling of pulp beverages in 38-neck PET plastic bottles, and can also be used for hot filling of other beverages. The filling valve adopts a streamlined large-flow outflow design, with fast filling speed and high output, and can be filled with pulp beverages with a particle size of less than 5 mm. The patented pulp fillingvalve is proprietary to our company. A stirring mechanism is set on the filling tank, and the rotation speed is adjustable. The pulp beverage is mixed evenly under dynamic conditions, and the filling accuracy is guaranteed. The large fruit grain filling machine is a special equipment for 38-neck PET bottle to fill the pulp beverage twice. The fruit filling machine adopts the patented "built-in plunger + non-touch" fruit filling valve of Langfang Bestcrown. The filling volume is 250~300ml (can be customized), and the standard fruit/juice ratio is 1:1~1:2; the machine is equipped with a CIP cleaning system. Strict control of the size of the pulp and grains, and the suitable bottle shape (curved shoulder) can be designed according to the specific conditions of customers.

Technical Parameters:

Filling temperature: 65-85℃

Capacity range: 8000BPH -36000BPH (500ml)

Applicable bottle type: 200ml-2000ml

Special model for small fruit grain products (fruit <5mm)

Special model for large fruit grain products (5mm＜fruit＜15mm)

The small fruit grain valve adopts a one-time eccentric national patent filling valve.

The large fruit grain valve adopts a piston filling valve, and the liquid adopts a mechanical negative pressure filling valve

Applications:

Minimum Order Quantity: 1

Price: USD 3000~2000000

Payment Terms: L/C, T/T

Delivery Time: 15 working days to 180 working days

Packaging Details: wooden box or pallet

Supply Ability: 30 lines per year

Product Application Occasions and Scenarios:

The Automatic Water Filling System is a versatile solution for various industries and settings. Here are some common scenarios where this product excels:

1. Bottling Plants: The Flow Meter Filling Machine is ideal for bottling plants where efficiency and accuracy are crucial. It can handle different bottle sizes and shapes, making it a versatile choice for filling operations.

2. Beverage Industry: The 3-10L Water Filling Machine is perfect for the beverage industry, including water bottling companies, juice manufacturers, and soft drink producers. It ensures consistent fill levels and minimizes wastage.

3. Manufacturing Facilities: With a wide price range of USD 3000 to 2000000, the water filling line is suitable for manufacturing facilities of all sizes. Whether it's a small startup or a large-scale production plant, this system can meet the demand.

4. Retail Stores: Retail stores that sell bottled water or other beverages can benefit from the efficiency of this filling system. It helps streamline the filling process and maintain product quality.

5. Export Markets: With flexible payment terms of L/C, T/T and a delivery time of 15 to 180 working days, this water filling line is well-suited for international markets. The packaging details in wooden boxes or pallets ensure safe transit.

Overall, the Automatic Water Filling System caters to a wide range of applications, offering reliability, precision, and efficiency for various industries and scenarios.

Support and Services:

Our Product Technical Support and Services for the Water Filling Line include:

- Installation and setup guidance for the water filling line equipment

- Training sessions for operators on how to use the equipment efficiently

- Troubleshooting assistance for any technical issues that may arise

- Regular maintenance services to ensure optimal performance of the water filling line

- Upgrades and enhancements to keep the equipment up-to-date with the latest technology

Packing and Shipping:

This Water Filling Line product comes in sturdy cardboard packaging to ensure safe delivery to your doorstep. Each component is securely wrapped and cushioned to prevent any damage during transit.

For shipping, we partner with reliable carriers to deliver your Water Filling Line product promptly and efficiently. You can track your order every step of the way to know exactly when it will arrive.
